Performance | |
---|---|
Chipset | Intel® Celeron 3855U/3865U/Core I3/I5/I7 |
RAM | 4GB DDR4, MAX 16GB |
Hardware Monitor | Monitors voltage, CPU, TEMP |
Watchdog Timer | 0-255 sec By Software |
Storage | SSD: Standard 64GB, Max 512GB |
Power | |
Power Supply | 9-36V DC(Onboard Wide power range with isolation, standard 12V/5A adapter) |
O/S | |
O/S | Windows 10, Linux |
I/O Port | |
USB | 4*USB 3.0+2*USB 2.0 |
Ethernet | 2*Intel 1000Mbps |
COM | 6*RS232(COM1~4 with isolation,COM3~4 can be switched to RS485/RS422 by jumper) |
Audio | 1*Line-out+1*Mic-in |
Display | 1*VGA+1*HDMI |
Extension | 1*Mini PCIe(WIFI/BT/3G/4G optional) |
Environmental | |
Anti-vibration | 5-19Hz/1.0mm amplitude; 19-200Hz/1.0g, acceleration |
Anti-shock | 10g acceleration, 11ms duration |
Reliability | MTBF≥5000h; MTTR≤0.5h |
Operating Temperature | -20℃~70℃(with air flow) |
Storage Temperature | -30℃~80℃ |
Operating Humidity | 95% @40℃, non-condensing |
Mechanical | |
Dimensions | 211.5mm(L)x200mm(W)x67mm(H) |
Material | High-strength and elegant Al-alloy, Fanless Design |
Weight | 2.6Kg/3.5Kg(NET/Gross) |
Color | Black |
Type | Description |
---|---|
PC-GS5071E | 3855U/4G/64G/6USB/6RS232/2LAN/VGA/HDMI/12V5A |
PC-GS5071E | 3865U/4G/64G/6USB/6RS232/2LAN/VGA/HDMI/12V5A |
PC-GS5073E | 6th Gen I3/4G/64G/6USB/6RS232/2LAN/VGA/HDMI/12V5A |
PC-GS5075E | 6th Gen I5/4G/64G/6USB/6RS232/2LAN/VGA/HDMI/12V5A |
PC-GS5077E | 6th Gen I7/4G/64G/6USB/6RS232/2LAN/VGA/HDMI/12V5A |
PC-GS5074E | 7th Gen I3/4G/64G/6USB/6RS232/2LAN/VGA/HDMI/12V5A |
PC-GS5076E | 7th Gen I5/4G/64G/6USB/6RS232/2LAN/VGA/HDMI/12V5A |
PC-GS5078E | 7th Gen I7/4G/64G/6USB/6RS232/2LAN/VGA/HDMI/12V5A |
