PC-GS507XA-4P
Features
- Onboard Intel®Celeron 3855U/3865U Core 6th /7 Gen I3/I5/I7 Processor
- 4GB DDR4, up to 16GB
- 2*USB 2.0+4*USB 3.0
- 5*Intel I211AT(4*POE-802.3af)
- Fanless High-strength and elegant Al-alloy case Design
Specifications
Ordering Information
Downloads
Specifications
| Performance | |
|---|---|
| Chipset | Onboard Intel Celeron 3855U/3865U; Core 6th / 7 Gen I3/I5/I7 Processor |
| RAM | 4GB DDR4, Max 16GB |
| Hardware Monitor | Voltage & CPU Temperature Monitoring |
| Watchdog Timer | 0-255 sec By Software |
| Storage | SSD: Standard 64GB, Max 512GB |
| Power | |
| Power Supply | 9-36V DC(12V/5A adapter) |
| O/S | |
| O/S | Windows 10、Linux(J1900 also support Win 7) |
| I/O Port | |
| USB | 4*USB2.0 +2*USB 3.0 |
| Ethernet | 5*Intel 1000Mbps (4*POE) |
| COM | 2*RS2323(RS422/RS485 optional) |
| Audio | 1*Line out, 1*Mic in |
| Display | 1*VGA, 1*HDMI |
| GPIO | 1*16 in/out |
| Extension | 1*Mini PCIe(WIFI/BT/3G/4G optional) |
| Environmental | |
| Anti-vibration | 5-19Hz/1.0mm amplitude; 19-200Hz/1.0g, acceleration |
| Anti-shock | 10g acceleration, 11ms duration |
| Reliability | MTBF≥5000h; MTTR≤0.5h |
| Operating Temperature | -20℃～70℃(with air flow) |
| Storage Temperature | -30℃～80℃ |
| Operating Humidity | 95% @40℃, non-condensing |
| Mechanical | |
| Dimensions | 211.5mm(L)x200mm(W)x67mm(H) |
| Material | High-strength and elegant Al-alloy, Fanless Design |
| Weight | 1.8Kg/2.3Kg(NET/Gross) |
| Color | Black |
Ordering Information
| Type | Description |
|---|---|
| PC-GS5071A-4P | 3855U/4G/64G/6USB/2RS232/5LAN/VGA/HDMI/12V5A |
| PC-GS5072A-4P | 3865U/4G/64G/6USB/2RS232/5LAN/VGA/HDMI/12V5A |
| PC-GS5073A-4P | 6th Gen I3/4G/64G/6USB/2RS232/5LAN/VGA/HDMI/12V5A |
| PC-GS5075A-4P | 6th Gen I5/4G/64G/6USB/2RS232/5LAN/VGA/HDMI/12V5A |
| PC-GS5077A-4P | 6th Gen I7/4G/64G/6USB/2RS232/5LAN/VGA/HDMI/12V5A |
| PC-GS5074A-4P | 7th Gen I3/4G/64G/6USB/2RS232/5LAN/VGA/HDMI/12V5A |
| PC-GS5076A-4P | 7th Gen I5/4G/64G/6USB/2RS232/5LAN/VGA/HDMI/12V5A |
| PC-GS5078A-4P | 7th Gen I7/4G/64G/6USB/2RS232/5LAN/VGA/HDMI/12V5A |
Downloads
| This product has no downloads. |
