PC-GS6801D
Features
- Intel® H81 Express Chipset 4th Generation Intel® Core/Celeron processors
- OS: Windows 10、Linux
- Memory: 2*U-DIMM DDR3, up to 16GB
- 12*USB2.0+2*USB3.0; 10*RS232
- Al-alloy, Fanless design
Specifications
Ordering Information
Downloads
Specifications
| Performance | |
|---|---|
| Chipset | Intel H81 Express Chipset 4th Generation Intel Core/ Celeron processors |
| RAM | 2*U-DIMM DDR3, Max 16GB |
| Hardware Monitor | Monitors voltage, CPU, TEMP |
| Watchdog Timer | 0-255 sec by software |
| Storage | 3.5″ HDD |
| Power | |
| Power Supply | ATX power supply 220V AC input, 300W power |
| O/S | |
| O/S | Windows 10, Linux(J1900 also support Win 7) |
| I/O Port | |
| USB | 12*USB 2.0+2*USB3.0 |
| Ethernet | 2*Intel 1000Mbps |
| COM | 10*RS232 |
| Display | 1*VGA+1*HDMI |
| Extension | 1*Mini PCIe(WIFI/BT/3G/4G optional) |
| Environmental | |
| Anti-vibration | 5-19Hz/1.0mm amplitude; 19-200Hz/1.0g, acceleration |
| Anti-shock | 10g acceleration, 11ms duration |
| Reliability | MTBF≥5000h; MTTR≤0.5h |
| Operating Temperature | -20℃～70℃ with air flow |
| Storage Temperature | -30℃～80℃ |
| Operating Humidity | 95% @40℃, non-condensing |
| Mechanical | |
| Dimensions | 355mm(L)*200mm(W)*130mm(H) |
| Material | Fanless High-strength and elegant Al-alloy panel |
| Weight | 6.58KG(NW)/8.29KG(GW) |
| Color | Black |
Ordering Information
| This product has no ordering information. |
Downloads
| This product has no downloads. |
