PPC-GS0853T-JK4
Features
- 8" Industrial display, Resistive touch screen(capacitive touch Optional)
- Chipset: Intel® Atom E3845 processor
- Onboard 2GB RAM
- Provide 3*USB+3*COM port
- Front Panel IP65
Specifications
Ordering Information
Downloads
Specifications
| Display | |
|---|---|
| Screen | 8 TFT LCD |
| Resolution | 800*600 |
| Brightness | 350 cd/m2 |
| Contrast | 500:1 |
| Touchscreen | Standard Resistive touch screen (capacitive screen Optional) |
| Standard Resistive touch screen (capacitive screen Optional) | |
| Chipset | Intel® Atom E3845 Processor |
| RAM | Standard 2GB onboard (4GB optional MOQ required) |
| Hardware Monitor | Monitors voltage, CPU, TEMP |
| Watchdog Timer | 0-255 sec by software |
| Storage | SSD: Standard 32GB, up to 512GB |
| Power | |
| Power Supply | 9-18V DC |
| O/S | |
| O/S | Windows 7, Windows 10, Linux |
| I/O Port | |
| USB | 3*USB 2.0 (1 on rear panel, 2 w. extended cable) |
| Ethernet | 1*1000M LAN |
| COM | 3*RS232(from extended cable) |
| Audio | 1*Line-out |
| Environmental | |
| Anti-vibration | 5-19Hz/1.0mm amplitude; 19-200Hz/1.0g, acceleration |
| Anti-shock | 10g acceleration, 11ms duration |
| IP Level | Front panel IP65 |
| Reliability | MTBF≥5000h; MTTR≤0.5h |
| Operating Temperature | -10℃～60℃ with air flow |
| Storage Temperature | -30℃～70℃ |
| Operating Humidity | 95% @40℃, non-condensing |
| Mechanical | |
| Dimensions | 220mm(L)*172mm(W)*42.2mm(H) |
| Mounting size | VESA mounting: 100*100mm; Embedded mounting: 193*165mm |
| Material | Fanless High-strength and elegant Al-alloy panel+PPS |
| Weight | NW/GW: 1.38KG/2.66KG |
| Color | Black front panel/Silver housing |
