PPC-GS1051T-JK4
Features
This product has no features.
Specifications
Ordering Information
Downloads
Specifications
| Display | |
|---|---|
| Screen | 9.7 TFT LCD |
| Resolution | 1024*768 |
| Brightness | 350 cd/m2 |
| Contrast | 500:1 |
| Touchscreen | 5-wire Resistive touch screen |
| Performance | |
| Chipset | Intel® Celeron®J1900 Processor |
| RAM | Standard 2GB DDR3, up to 8GB |
| Hardware Monitor | Monitors voltage, CPU, TEMP |
| Watchdog Timer | 0-255 sec by software |
| Storage | SSD: Standard 32GB, up to 512GB |
| Power | |
| Power Supply | 9-28V DC |
| O/S | |
| O/S | Windows 7, Windows 10, Linux |
| I/O Port | |
| USB | 3*USB 2.0(from extended cable), 1*USB3.0(on product panel) |
| Ethernet | 2*1000M LAN(one from extended cable, one on rear panel) |
| COM | 3*RS232+2*RS485(from extended cable) |
| Audio | 1*Line-out+1*Mic-in, 2*Built-in speaker |
| Environmental | |
| Anti-vibration | 5-19Hz/1.0mm amplitude; 19-200Hz/1.0g, acceleration |
| Anti-shock | 10g acceleration, 11ms duration |
| IP Level | Front panel IP65 |
| Reliability | MTBF≥5000h; MTTR≤0.5h |
| Operating Temperature | -20℃～60℃ with air flow |
| Storage Temperature | -30℃～70℃ |
| Operating Humidity | 95% @40℃, non-condensing |
| Mechanical | |
| Dimensions | 243mm(L)*198mm(W)*42mm(H) |
| Mounting size | VESA mounting: 100*100mm; Embedded mounting: 193*165mm |
| Material | Fanless High-strength and elegant Al-alloy panel+PPS |
| Weight | 1.67kg(NET) |
| Color | Black front panel & silver housing |
Ordering Information
| This product has no ordering information. |
Downloads
| This product has no downloads. |
