PPC-GS1092T
Features
- 10.1" Multi-point capacitive touch screen
- Chipset: RK3288 SoC Cortex-A17 Quad Core @ 1.8GHz Max
- Onboard 2GB EMMC (4GB optional MOQ required)
- Provide 2*USB+4*COM port
- Support 1*1000M LAN port
Specifications
Ordering Information
Downloads
Specifications
| Display | |
|---|---|
| Screen | 10.1 TFT LCD |
| Resolution | 1280*800 |
| Brightness | 350 cd/m2 |
| Touchscreen | Multi-point capacitive touch screen |
| Performance | |
| Chipset | RK3288 SoC Cortex-A17 Quad Core @ 1.8GHz Max |
| RAM | Onboard 2GB EMMC (4GB optional MOQ required) |
| Hardware Monitor | Monitors voltage, CPU, TEMP |
| Watchdog Timer | 0-255 sec by software |
| Storage | 8GB NAND Flash |
| Power | |
| Power Supply | 12V DC (with adapater) |
| O/S | |
| O/S | Android 5.1.1 |
| I/O Port | |
| USB | 2*USB 2.0 |
| Ethernet | 1*1000M LAN |
| COM | 4*RS232 (1*RS485 optional) |
| Audio | 1*Line-out/In |
| Display | 1*HDMI |
| GPS | 1*HDMI |
| GPS | Optional |
| SD/TF | 1*TF card slot(Max capacity up to 128G) |
| SIM | 1*SIM card slot |
| MiniPCIe | 1*MiniPCIe(optional 3G/4G ) |
| Environmental | |
| Anti-vibration | 5-19Hz/1.0mm amplitude; 19-200Hz/1.0g, acceleration |
| Anti-shock | 10g acceleration, 11ms duration |
| IP Level | Front panel IP65 |
| Reliability | MTBF≥5000h; MTTR≤0.5h |
| Operating Temperature | -10℃～50℃ with air flow |
| Storage Temperature | -20℃～60℃ |
| Operating Humidity | 95% @40℃, non-condensing |
| Mechanical | |
| Dimensions | 268mm(L)*195mm(W)*52.5mm(H) |
| Mounting size | VESA mounting: 100*100mm; Embedded mounting: 243*155mm |
| Material | Fanless High-strength and elegant Al-alloy panel |
| Weight | 1.45kg/2.31kg(NET/Gross) |
| Color | Black |
