TPC-GS0881
Features
- 8" Industrial display, high brightness screen optional
- Chipset:Intel® Cherry trail Z8350
- Dual channel WiFi (2.4GHZ+5GHZ)
- Onboard 4GB RAM
- Slim design, Rugged Mobile Terminal
Specifications
Ordering Information
Downloads
Specifications
| Display | |
|---|---|
| Screen | 8 IPS LCD Gorilla Glass 3rd Gen; Hardness: 7H |
| Resolution | 800*1280 |
| Brightness | 400 cd/m2 (800 cd/m2 optional) |
| Contrast | 800:1 |
| Touchscreen | multi-point capacitive touch |
| Performance | |
| Chipset | Intel® cherry trail Z8350 1.44 GHz~1.92 GHz |
| RAM | Onboard 4GB (2GB optional MOQ) |
| Hardware Monitor | Monitors voltage, CPU, TEMP |
| Watchdog Timer | 0-255 sec by software |
| Storage | Onboard 64GB EMMC (32GB optional MOQ) |
| Power | |
| Power Supply | 5V DC (Standard 5V/3A adapter) |
| Battery | 9800 mAh, 3.8V |
| O/S | |
| O/S | Win10 Pro/Win10 IOT/Win10 Home |
| Camera | |
| Camera | Front 2.0 MP / Back 5.0 MP, Auto-Focus |
| Flash Light | |
| Flash Light | support |
| I/O Port | |
| USB | 1*USB 2.0 Type A, 1*USB 2.0 Type C |
| WIFI | 802.11(a/b/g/n/ac), support 2.4GHZ+5GHZ |
| Audio | Speaker/MIC/3.5mm earphone |
| Display | 1*Mini HDMI |
| Bluetooth | 4.1 (BLE) class1 transmission distance :10 m |
| GPS | MT6630 |
| SD/TF | 1* Micro SD |
| SIM | 1*SIM 2G, 3G, 4G |
| DC_IN | 1*PWR_IN |
| Pogo Pin | 1*Pogo Pin (12 Pin) |
| Extension | Optional: HF RFID/UHF RFID/GPS/NFC//1D/2D/CAN/ Fingerprint reader |
| Accessoires | |
| Pen | Capacitive pen, Hand strap optional |
| Environmental | |
| Anti-vibration | 5-19Hz/1.0mm amplitude; 19-200Hz/1.0g, acceleration |
| Anti-shock | 10g acceleration, 11ms duration |
| IP Level | IP67 |
| Reliability | MTBF≥50000h; MTTR≤0.5h |
| Operating Temperature | -10℃～50℃ with air flow |
| Storage Temperature | -30℃～70℃ |
| Operating Humidity | 95% @40℃, non-condensing |
| Mechanical | |
| Dimensions | Standard: 227mm(L)*142mm(W)*20mm(H); Optional with UHF:227mm(L)*142mm(W)*29.5mm(H) |
| Mounting size | VESA mounting |
| Material | ABS+PC; TPU |
| Weight | 0.7KG/1.2KG (NW/GW) |
| Color | Black |
Ordering Information
| This product has no ordering information. |
Downloads
| This product has no downloads. |
