TY185-GS51C/TY185-GS7XC

18.5" industrial display, Multi-Point Capacitive touch Screen / Front Panel IP65
Chipset:Intel® Celeron J1900/Core I3/I5/I7
Provide 6* USB+2* COM (optional 6* COM)
DDR3L RAM, up to 16GB
Provide 2* GbE LAN RJ45 1000M
Fanless High-strength and elegant slim design

Specifications

Ordering Information

Downloads

Specifications

Display
Screen	18.5″ TFT LCD
Resolution	1366*768
Brightness	250 cd/m2
Contrast	1000:1
Touch Screen	Multi-Point Capacitive touch
Performance
Chipset	Intel® Celeron J1900/Core I3/I5/I7
RAM	4G DDR3L RAM, Up to 8GB
Hardware Monitor	Monitors voltage, CPU, TEMP
Watchdog Timer	Support hardware reset function (256 levels, 0~255 seconds)
Storage	SSD 64GB up to 512GB
Power
Power Supply	12V DC input (12/5A power adapter; 9-36V DC IN optional)
O/S
O/S	Windows 7/10, Linux
I/O Port
USB	5USB2.0 +1USB3.0
Ethernet	1~2* GbE Lan
COM	2RS232, 1RS485 Optional
Audio	1Line-out+1Mic
Display	1VGA, 1HDMI
Mini PCIE	1*Mini PCIe (WiFi/BT/3G/4G/5G Optional)
GPIO	1* 4 in/4 out
Environmental
Anti-vibration	5-19Hz/1.0mm amplitude; 19-200Hz/1.0g, acceleration
Anti-shock	10g acceleration, 11ms duration
IP Level	Front panel IP65
Reliability	MTBF≥50000h; MTTR≤0.5h
Operating Temperature	0℃～50℃ with air flow
Storage Temperature	-30℃～70℃
Operating Humidity	95% @40℃, non-condensing
Mechanical
Dimensions	473.1295.356.2mm
Mounting size	VESA mounting: 100100mm, Embedded installation: 452.97277.27mm
Material	Fanless High-strength and elegant Al-alloy panel
Weight	6.25 kg / 7.45 kg (N.W./G.W.)
Color	Black/Silver
