Display | |
---|---|
Screen | 21.5″ TFT LCD |
Resolution | 1920*1080 |
Brightness | 250 cd/m2 |
Contrast | 1000:1 |
Touch Screen | Multi-Point Capacitive touch |
Performance | |
Chipset | Intel® Celeron J1900 processor |
RAM | 4GB DDR3L, up to 8GB |
Hardware Monitor | Monitors voltage, CPU, TEMP |
Watchdog Timer | Support hardware reset function (256 levels, 0~255 seconds) |
Storage | SSD 64GB up to 512GB |
Power | |
Power Supply | 9~24V DC Input (9~36V DC optional) 12V/5A power Adapter |
O/S | |
O/S | Windows 7/10, Linux |
I/O Port | |
USB | 3*USB 2.0 + 1*USB3.0 (Celeron J1900) |
Ethernet | 1* RJ45 Gigabit Ethernet (Intel I211-AT) |
COM | 2*RS232 (1*RS422/RS485 optional ) |
Audio | 1*Line-out, 1*Mic-in |
Display | 1*VGA, 1*HDMI |
Mini PCIE | 1*Mini PCIe (WiFi/BT/3G/4G/5G Optional) |
GPIO | 1* 4 in/4 out |
Environmental | |
Anti-vibration | 5-19Hz/1.0mm amplitude; 19-200Hz/1.0g acceleration |
Anti-shock | 10g acceleration, 11ms duration |
IP Level | Front panel IP65 |
Reliability | MTBF≥50000h; MTTR≤0.5h |
Operating Temperature | -10℃~50℃, with airflow |
Storage Temperature | -20℃~60℃ |
Operating Humidity | 95% @40℃, non-condensing |
Mechanical | |
Dimensions | 543*334.4*56.2mm |
Mounting size | VESA mounting: 100*100mm, Embedded installation: 523*314.4mm |
Material | Fanless High-strength and elegant Al-alloy panel |
Weight | 8.31 kg/ 9.85 kg (N.W./G.W.) |
Color | Black/Silver |
Type | Description |
---|---|
TY215-GS51C | 21.5″/J1900/4G/64G/6USB/2RS232/1LAN/VGA/HDMI/12V5A |
TY215-GS73C | 21.5″/i3/4G/64G/6USB/2RS232/1LAN/VGA/HDMI/12V5A |
TY215-GS75C | 21.5″/i5/4G/64G/6USB/2RS232/1LAN/VGA/HDMI/12V5A |
TY215-GS77C | 21.5″/i7/4G/64G/6USB/2RS232/1LAN/VGA/HDMI/12V5A |
This product has no downloads. |
